Jaw Crusher
The Elkamak Jaw Crusher is designed for the primary crushing of hard and abrasive materials through powerful compression. Its hydraulic discharge-opening adjustment, robust construction and low maintenance requirements make it a reliable solution for quarries, mining operations and recycling plants.
JWC 60 · +4 models
- Feed Opening
- 610x350mm
- Discharge Setting
- 40-150mm
- Capacity
- 30-90t/h
- Motor Power
- 30kW
Overview
Elkamak Jaw Crusher
The Elkamak Jaw Crusher is engineered to reduce large and demanding materials into smaller, manageable sizes during the primary crushing stage. Its powerful compression principle delivers reliable and effective crushing performance, particularly when processing hard and abrasive materials.
Working Principle
Crushing takes place between two jaws, one fixed and one moving. Driven by an eccentric shaft, the moving jaw travels back and forth, compressing the material against the fixed jaw. Once the material reaches the required size, it is discharged by gravity through the adjustable lower opening.
Application Areas
- Quarries and crushing-screening plants
- Mining operations
- Construction and demolition waste recycling
- Iron, steel and metallurgical industries
- Infrastructure projects
- Construction material production
- Concrete recycling plants
Key Advantages
- High crushing performance on hard and abrasive materials
- Easy and quick product-size adjustment with a hydraulic system
- Robust construction and long service life
- Low maintenance requirements
- Flexible operation for different production needs
- Wide range of applications
- Safety-focused and operator-friendly design
With its robust construction, high performance and ease of operation, the Elkamak Jaw Crusher provides an efficient and dependable primary crushing solution for mining, construction and recycling applications.
Models & Specifications
| Model | Feed Opening(mm) | Discharge Setting(mm) | Capacity(t/h) | Motor Power(kW) | Weight(kg) |
|---|---|---|---|---|---|
| JWC 60 | 610x350 | 40-150 | 30-90 | 30 | 5.800 |
| JWC 90 | 900x650 | 50-150 | 60-200 | 75 | 7.150 |
| JWC 110 | 1100x850 | 80-200 | 100-300 | 132 | 33.450 |
| JWC 130 | 1300x1000 | 110-250 | 300-600 | 160/200 | 42.850 |
| JWC 150 | 1400x1200 | 120-260 | 350-900 | 200 | 51.000 |
